The 400GBASE-XDR4 module, MTP/MPO-12 connector, up to 2km over parallel single-mode fiber. It is compliant with QSFP112 MSA, CMIS 4.0 Interface and 400GAUI-4 standards.
Specifications
Form Factor: QSFP112
Max Data Rate: 425Gbps (4×106.25Gb/s)
Wavelength: 1310nm
Max Cable Distance: 2km
Connector: MTP/MPO-12 (APC)
Media: SMF
Transmitter Type: EML
Receiver Type: PIN
TX Power: -2.4~4dBm
RX Power: -4.5~5.5dBm
Power Budget: 4dB
Modulation: 4x 106.25G PAM4
Power Consumption: ≤10W
Extinction Ratio: >3.5dB
DDM/DOM: Supported
Commercial Temperature Range: 0 to 70°C (32 to 158°F)
DSP: TX and RX
Inbuilt FEC: No
Core Size: 9μm
Packaging Technology: COC
Protocols: IIEEE 802.3bs, OIF-CEI-112G-VSR-PAM4, CMIS Rev 5.2, QSFP-112 MSA
Warranty: 5 Years
