Adopting a 2 megapixel progressive scan CMOS sensor, the network camera can provide a high-definition professional surveillance and security solution. With the IR and warm light, the camera can also deliver clear video at night. Designed for indoor and outdoor environments, it is IP66 weatherproof, ideal for squares, office buildings, government, industrial parks, etc. It is compatible with ONVIF protocol, enabling interoperability with numerous third-party devices.
Specifications
Case Type
Dome
Image Sensor
1/2.8″ Progressive Scan CMOS
Max. Resolution
2 Megapixel
Focal Length
2.8mm, Fixed; 2.8-12mm, Varifocal
Max. Frame
1920×1080 @25fps
Aperture
F1.6
IR Range
Up to 10m (33 ft)
Field of View
106.6° ~ 30.6°(H), 56.5° ~ 17.4°(V), 138.6° ~ 37.6°(D)
Min.Illumination
Color:0.002 lux (F1.6, AGC ON)
0 lux with IR/Warm light
0 lux with IR/Warm light
WDR
120dB (Fixed Lens)
Audio
Built-in Microphone & Speaker
Digital Noise Reduction
2D/3D DNR
Video Compression
Ultra 265, H.265, H.264, MJPEG
Operating Temperature
-20 to 60℃(-4 to 140°F)
Power Supply
DC12V, PoE+(IEEE 802.3at)
Operating Humidity
≤95% RH (Non-condensing)
Max. Power Consumption
16W
Ingress Protection
IP66
Interoperability
ONVIF® Profile G, ONVIF® Profile S Specification at onvif.org
Dimensions (ØxH)
Wall Mount: 5.3” x 7.6” x 11.9” (134 x 192 x 302mm)
