RS2110 is a 1U rackmount server based on Intel CoffeeLake architecture, supporting the latest Intel I3/Xeon E-2100 series processor with up to 6 cores. The memory is up to 128GB and accommodates 4x 3.5” hot-swap hard drives. With an integrated BMC chip, it enables convenient management and supports I/OA technology, link aggregation, and binding redundancy. It features a dedicated 1000M IPMI remote management port, optional KVM OVER IP out-of-band management, and standard 450W dual power supplies.
Specifications
Form Factor
1U Rackmount
Number of Processors
1
Chipset
Intel C242 Chipset
Memory
DDR4 ECC/Unbuffered (UDIMM) 2666MHz RAM, Up to 128GB
Drive Bays
4x 3.5”/2.5” SAS/SATA/SSD Hot-swappable Drive Bays
Expansion Slots
2 PCIe 3.0x 8
Raid Controller
Standard Configuration – No Raid Card
Weight
24lbs (10.88KG)
Ethernet
2x 1GBase-T Ports
Power Supply
450W 1+1 Redundant Power Supply
Dimensions (HxWxD)
1.7″x16.9″x21.7″ (44x430x550mm)
Fans
4 Non-hot-swappable Fans
Management Software
BIOS | BMC | IPMI2.0 | iKVM
Operating System Management
Windows Server 2019 | CentOs Linux 8.0
