The RS3110 is a high-performance computing server with Intel C246 chipset. It supports 8th/9th gen Intel® Core™ i3/i5/i7/i9 series and Intel® Xeon® E-2100/2200 series processors. The CPU includes integrated core graphics with hardware decoding and up to 1080P transcoding capability. It supports up to 128GB memory and 4x 3.5″/2.5″ SATA hot-swappable drives. Integrated BMC chip enables easy management, I/OA tech, link convergence, and binding redundancy. Optional KVM OVER IP for out-of-band management.
Specifications
Form Factor
1U Rackmount
Processor
1x Intel Xeon E-2224G Processor – 3.5GHz/8M/4C/4T/Graphics P630/71W
Chipset
Intel C246 Chipset
Memory
DDR4 ECC/Unbuffered (UDIMM) 2666MHz RAM, Up to 128GB
Drive Bays
4x 3.5”/2.5” SATA Hot-swappable Drive Bays
RAM
Standard Configuration – 1x 16GB DDR4 2666MHz ECC DDR4 RAM
Hard Drives
Standard Configuration – 1x 2TB 3.5” SATA 7200RPM
Expansion Slots
1 PCIe 3.0x 8
Raid Controller
Standard Configuration – No Raid Card
Power Supply
450W 1+1 Redundant Power Supply
Ethernet
2x 1GBase-T Ports
Fans
4 Non-hot-swappable Fans
Management Software
BIOS | BMC | IPMI2.0 | iKVM
Operating System Management
Windows Server 2019 | CentOs Linux 8.0
Dimensions (HxWxD)
1.7″x16.9″x21.7″ (44x430x550mm)
Gross Weight
37lbs (17KG)
