The RS7150-V3 is a high-performance computing server with Intel® C741 chipset. It supports 4th/5th gen Intel® Xeon® Scalable processors. It supports up to 8 TB memory and 8x 2.5″ NVMe/SAS/SATA hot-swappable drives, with optional support for 2x M.2 NVMe/SATA slot(s). Integrated BMC chip enables easy management, I/OA tech, link convergence, and binding redundancy. Optional KVM OVER IP for out-of-band management.
Specifications
Form Factor
1U Rackmount
Processor
Standard Configuration-2x Intel® Xeon® Silver 4410Y Processor-12C 2.0G 150W
Chipset
Intel® C741
Drive Bays
Standard Configuration-2x 480G 2.5″ SATA SSD Total 8 Bay(s)
Memory
Standard Configuration-4x 32G DDR5 RDIMM
Expansion Slots
Standard Configuration-1 PCIe 5.0×16, 2 PCIe 5.0x 16
Raid Controller
Support RAID 0,1,5,10
Fans
8 Counter-Rotating 40x40x56mm Fan(s)
Ethernet
Standard Configuration-2-port 10GBase-T(AIOM)
Power Supply
2x 1200W Redundant Titanium Level (96%) Hot-plug Power Supplies
System BIOS
AMI 64MB SPI Flash
Operating Temperature
10°C ~ 35°C (50°F ~ 95°F)
Management Software
BMC Web GUI/Redfish APIs/IPMI 2.0/SNMP3.0
Operating System Management
WS 2022/RHEL 9.0/ESXi 8.0
Chassis (HxWxD)
437x43x747mm (17.2″x1.7″x29.4″)
Gross Weight
49 lbs (22.2 kg)
