S5810-48FS, a next-gen L3 switch with 48x 1G SFP downlinks and 4x 10G SFP+ uplinks. Pre-loaded with PicOS®, equipped with comprehensive SDN features and compatible
Specifications
Ports
48x 1G SFP | 4x 1G/10G SFP+
Switch Chip
BCM56340
Switching Capacity
176 Gbps
Operating System
PicOS®
Forwarding Rate
132 Mpps
MAC Address
65,536
SDRAM
1GB
ARP
12,000
Flash Memory
512MB
Input Voltage
100-240VAC, 50-60Hz, 3A Max
Latency
6.54μs
Power Output
150W
Packet Buffer
4MB
Max. Power Consumption
<100W
Power Supply
2 (1+1 Redundancy) Hot-swappable
IPv4/IPv6 Routes
6,000/3,000
Fan Number
3 (2+1 Redundancy) Built-in
Dimensions (HxWxD)
1.73”x17.32”x13.39” (44x440x340mm)
Airflow
Left-to-Right
Temperature
Operating: 0 to 50ºC (32 to 122°F)
Storage: -40 to 70ºC (-40 to 158°F)
Storage: -40 to 70ºC (-40 to 158°F)
