IES3100-8VF features 8x 10/100/1000BASE-T RJ45 ports, 2x 100/1000/2500BASE-X SFP ports, which is designed especially for a broad spectrum of industrial and extended enterprise connectivity needs. With an IP40 rated metal enclosure and fanless design, it can operate within a wide temperature range of -40 to 75°C (-40 to 167°F). This switch is ideal for harsh environments, such as distribution centers, warehouses, and outdoor places with extremely low or high temperatures. This layer 2 industrial managed switch supports enhanced L2+ functions such as 802.1Q VLAN and port-based VLAN, QoS, IGMP Snooping, LACP link aggregation, etc, can meet the requirements of many scenarios in industrial environments.
Specifications
Ports: 8x 10/100/1000BASE-T RJ45 | 2x 100/1000/2500BASE-X SFP
MAC Address: 8K
Switching Capacity: 26Gbps
Input Voltage: 18-60VDC
Forwarding Rate: 148,800 pps/100Mport – 1,488,000 pps/1000M port
Max. Power Consumption: 10W
Flash Memory: 256Mbit (32MB)
Operating Temperature: -40 to 75°C (-40 to 167°F)
Jumbo Frame: 9,000
Storage Temperature: -40 to 85°C (-40 to 185°F)
Packet Buffer: 4Mbit (512KB)
Operating Humidity: 5-95%(non‐condensing)
Fan Number: Fanless
Installation: DIN-rail Mount
Enclosure: IP40 Rated Metal Enclosure
Management: WEB GUI/SSH/Telnet/SNMP
Dimensions (HxWxD): 5.51”x2.04”x4.33” (140x52x110mm)
MTBF: ≥ 400,000 Hours
Please Note: Power cord is not included with this product, please purchase seperately.
